Principales caractéristiques
PUISSANCE |
15kW |
2 ÉTAGES |
1 x 6kW + 1 x 9kW |
TENSION |
400V 3-PH 5 Hz + terre |
INTENSITÉ |
22A |
LIQUIDE |
eau glycolée (25% max) |
Caractéristique
ÉLÉMENTS CHAUFFANTS |
incoloy 800 |
CORPS |
1" 1/4 AISI 304 |
ENTRÉE / SORTIE |
1" 1/4 |
CALORIFUGE |
EPDM mousse max 150° |
SUPPORT |
tole AISI 304 |
ARMOIRE ÉLECTRIQUE |
métallique IP55 avec presse étoupe |
POSITION |
horizontale |
PRESSION MAX D'UTILISATION |
7 bar |
T° SORTIE |
46°C max |
Organes de sécurité
THERMOSTAT A RÉARMEMENT MANUEL |
70°C |
3 FUSIBLES |
1 par phase |
